HPE Networking Instant On AP21 (RW) Dual Radio 2x2 Wi‑Fi 6 Access Point Pack of 5 | S1T18A

The HPE Networking Instant On Access Points AP21 is the low-density work horse of the Wi-Fi 6 series. Hosting up to 1.5 Gbps over its two dual-band antennas, this access point will bring high speed connectivity to areas 1500 square feet and smaller. The AP21 access point is ideal for set and forget deployments that need only 1-2 APs, like small retail stores, pop-up shops, and startups.

Wi-Fi antennaAntennas: Dual Omni-directional 2x2 MIMO
Antenna Gain:1.7 dBi in 2.4 GHz and 4.8 dBi in 5 GHz
Maximum transmit power:
5 GHz band: +21 dBm (+18 dBm per chain, 3 dB MIMO gain)
2.4 GHz band: +21 dBm (+18 dBm per chain, 3 dB MIMO gain)

Ports1 GbE Base-T uplink port
DC power connector
LED status indicators
Reset/LED control button
Kensington security slot

CertificationsWi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3

WarrantyInstant On 2-year warranty includes 24X7 phone support for the first 90 days and chat support. See the warranty duration.
Community support is available for the life of the product.

Connectivity, standardUltra-fast 802.11ax

Input voltagePoE: 802.3af (class 3) DC power (12V)

Note: Power sources are sold separately unless you purchase the bundle SKU

Power consumption10.1W (PoE) or 10.9W (DC)

MountingCeiling/Wall mount clip

Radio coverageDual-radio 802.11ax/n
2x2 5 GHz/2.4 GHz MIMO

DifferentiatorIn the Box: Bundle includes 5 access points, mount kits, and Ethernet cables.

HPE Networking Instant On Access Point 5-Pack
Quick Start guide
Combined ceiling and wall rail mount clip
Ethernet cable

For use in those countries and regions where no specific regulatory domain is required.
